Home>> RF Filter - Band Pass>> MFBT-00003PSM

MFBT-00003PSM

Surface Mount from Marki Microwave

Filter, Tunable, Band Pass, MMIC, 18000 MHz, 16000 MHz BW, 7.5 dB IL, SMT

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MFBT-00003PSM is a surface mount MMIC tunable filter for adaptive filtering applications. The MFBT-00003PSM offers separate low pass and high pass tuning capability, allowing users to create bandpass filters with variable center frequencies and % bandwidths. Performance features include low return loss in both the passband and stopband and low insertion loss, high stopband rejection, and high IP3 relative to other tunable filters. The MFBT-00003PSM is available as a 4x4mm plastic QFN, replacing much larger switched filter banks.

Part Number: MFBT-00003PSM
Manufacturer: Marki Microwave
Export Status:
Center Frequency: 18000 MHz
Bandwidth: 16000 MHz
Insertion Loss TYP: 7.5 dB
Return Loss Typ: 10 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MFBT-00003P Marki Microwave	Evaluation Board for MFBT-00003PSM

Technical Inquiry Request for MFBT-00003PSM RF Filter - Band Pass

Fields marked with * are required.

Product Specifications For MFBT-00003PSM RF Filter - Band Pass

Part Number: MFBT-00003PSM Manufacturer: Marki Microwave Product Description: Filter, Tunable, Band Pass, MMIC, 18000 MHz, 16000 MHz BW, 7.5 dB IL, SMT

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$267.12

5 - 9

$222.60

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
