Home>> Amplifier>> AMM-7199CH

AMM-7199CH

Bare Die from Marki Microwave

Amplifier, Driver, 11 to 38 GHz, 20.5 dB, +21 dBm, Chip

Status: No new designs | Data Sheet:

| RoHS Compliance: Rohs Compliant

Part Number: AMM-7199CH
Manufacturer: Marki Microwave
Export Status:
Type: Broadband, LO Drive
Frequency Min: 11 GHz
Frequency Max: 38 GHz
P1dB: 18 dBm
Psat: 21 dBm
Gain: 20.5 dB
IP3: 31 dBm
Noise Figure: 5.8 dB
Return Loss Input: 18 dB
Return Loss Output: 12 dB

No Content Available

Part Function	Part Number	Description
Replacement	AMM-7199ACH Marki Microwave	Amplifier, Driver, 11 to 38 GHz, 20 dB, +18 dBm, Chip

Technical Inquiry Request for AMM-7199CH Amplifier

Fields marked with * are required.

Product Specifications For AMM-7199CH Amplifier

Part Number: AMM-7199CH Manufacturer: Marki Microwave Product Description: Amplifier, Driver, 11 to 38 GHz, 20.5 dB, +21 dBm, Chip

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

On Order

by 5/15/2026

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

25 - 99

$137.95

100 - 499

$114.00

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices

Description	Units Per Format	Available

Description	Units Per Format	Available
