PE29101

High-speed FET Driver

UltraCMOS® High-speed FET Driver, 40 MHz

Status: Discontinued | Data Sheet:

| RoHS Compliance: Rohs Compliant

Key Features

•High- and low-side FET drivers •Dead-time control •Fast propagation delay, 11ns •Internal gate overvoltage management •Sub-nanosecond rise and fall time •2A/4A peak source/sink current •Packaging: Flip chip

Description

NOT RECOMMENDED FOR NEW DESIGNS (NRND) This product is not recommended for new designs. For more information, please contact your local sales representative. The PE29101 integrated high-speed driver is designed to control the gates of external power devices, such as enhancement mode gallium nitride (GaN) FETs. The outputs of the PE29101 are capable of providing switching transition speeds in the sub-nanosecond range for switching applications up to 40 MHz. High switching speeds result in smaller peripheral components and enable new applications such as wireless power charging and solid-state LiDAR.

Part Number: PE29101
Manufacturer: pSemi

	Datasheet
	Material Declaration
	RoHS Compliance Certificate
	REACH Compliance Certificate
	Application Note: PE29101/102 Footprint Requirements
	Application Note: Using Peregrine’s High-Speed FET Drivers

Part Function	Part Number	Description
Design Kit	EK29101-01 pSemi	Evaluation Kit for PE29101
Complementary Product	PE29102 pSemi	UltraCMOS® High-speed FET Driver, 33 MHz
