Home>> RF Mixer>> MMIQ-0106HCSM-2

MMIQ-0106HCSM-2

Surface Mount from Marki Microwave

RF Mixer, MMIC IQ, 1500 to 5500 MHz (RF/LO), +16 to +20 dBm (LO Drive), SMT-HC2

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

MMIQ-0106HCSM is a high linearity, passive GaAs MMIC IQ mixer. This is an ultra-broadband mixer spanning 1.5 to 5.5 GHz on the RF and LO ports with an IF from DC to 3 GHz. Up to 33 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. The MMIQ-0106HCSM is available in a 4x4 mm ceramic QFN package. Evaluation boards are available.

Part Number: MMIQ-0106HCSM-2
Manufacturer: Marki Microwave
Type: Double Balanced IQ
RF Frequency Range Min: 1500 MHz
RF Frequency Range Max: 5500 MHz
Operating LO Frequency Range Min: 1500 MHz
Operating LO Frequency Range Max: 5500 MHz
LO Drive Min: 16 dBm
LO Drive Max: 20 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 2000 MHz
IIP3: 22 dBm
Isolation LO-RF: 62 dB
Isolation LO-IF: 32 dB
Isolation RF-IF: 43 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MMIQ-0106HC Marki Microwave	Evaluation Board for MMIQ-0106HCSM-2
Complementary Product	ADM-8007PSM Marki Microwave	Amplifier, 2 to 40 GHz , 23 dB, +24 dBm, SMT

Technical Inquiry Request for MMIQ-0106HCSM-2 RF Mixer

Fields marked with * are required.

Product Specifications For MMIQ-0106HCSM-2 RF Mixer

Part Number: MMIQ-0106HCSM-2 Manufacturer: Marki Microwave Product Description: RF Mixer, MMIC IQ, 1500 to 5500 MHz (RF/LO), +16 to +20 dBm (LO Drive), SMT-HC2

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

25 - 99

$206.99

100 - 499

$171.08

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
