Home>> RF Filter - Band Pass>> MFBP-00053CH

MFBP-00053CH

Bare Die from Marki Microwave

Filter, Band Pass, MMIC, 18930 MHz, 7570 MHz BW, 1.4 dB IL, Chip

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MFBP-00053CH passive MMIC bandpass filter die is an ideal solution for small form factor, high rejection filtering. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit to unit variation than traditional filter technologies. The MFBP-00053CH is available as a wire bondable chip. Low unit to unit variation allows for accurate simulations using the provided S2P file taken from measured production units.

Part Number: MFBP-00053CH
Manufacturer: Marki Microwave
Filtering Technology: MMIC
Center Frequency: 18930 MHz
Bandwidth: 7570 MHz
Insertion Loss TYP: 1.4 dB
Return Loss Typ: 24.22 dB
Package: Bare Die
Length: 3.1 mm
Width: 2.4 mm
Height: 0.1 mm

No Content Available

Technical Inquiry Request for MFBP-00053CH RF Filter - Band Pass

Fields marked with * are required.

Product Specifications For MFBP-00053CH RF Filter - Band Pass

Part Number: MFBP-00053CH Manufacturer: Marki Microwave Product Description: Filter, Band Pass, MMIC, 18930 MHz, 7570 MHz BW, 1.4 dB IL, Chip

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$141.42

5 - 9

$115.71

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
