Home>> RF Attenuator>> ATN05-00110CH

ATN05-00110CH

Bare Die from Marki Microwave

Attenuator, Fixed, DC to 110 GHz, 5 dB, Chip

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The ATNXX-00110CH is a family of precision GaAs MMIC fixed attenuators. These attenuators are an ideal solution for attenuating a signal and they can be used in a wide range of applications. They are ideal for test equipment’s protection and signal overload prevention in various RF systems. A 50-ohm match is maintained over the entire operating frequency range. Attenuation values range from 0dB to 10dB with 1dB steps. ATN-110CH-KIT is an evaluation kit with 5 units of each value.

Part Number: ATN05-00110CH
Manufacturer: Marki Microwave
Frequency Min: 0 MHz
Frequency Max: 110000 MHz
Impedance: 50 Ohms
Insertion Loss Min: 5 dB

No Content Available

Part Function	Part Number	Description
Evaluation Board	ATN-110CH-KIT Marki Microwave	Evaluation Kit for ATNXX-00110CH Series

Technical Inquiry Request for ATN05-00110CH RF Attenuator

Fields marked with * are required.

Product Specifications For ATN05-00110CH RF Attenuator

Part Number: ATN05-00110CH Manufacturer: Marki Microwave Product Description: Attenuator, Fixed, DC to 110 GHz, 5 dB, Chip

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

On Order

by 11/12/2025

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$30.26

5 - 9

$25.22

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
