ADM-8095PSM

Surface Mount from Marki Microwave

Amplifier, HDR, Gain Block, 0.09 to 10 GHz, 18 dB, +21 dBm, SMT

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

Description:

The ADM-8095PSM is a high-linearity, low noise distributed amplifier capable of providing +20 dBm output power up to 10 GHz. The ADM-8095PSM can serve either as a linear signal amplifier, or as a saturated driver amplifier for H- or S-diode mixers. The amplifier has excellent return losses and gain flatness.

Part Number: ADM-8095PSM
Manufacturer: Marki Microwave
Type: Gain Block, LO Drive
Frequency Min: 0.09 GHz
Frequency Max: 10 GHz
P1dB: 18 dBm
Psat: 21 dBm
Gain: 18 dB
IP3: 30 dBm
Noise Figure: 1.2 dB
Return Loss Input: 17 dB
Return Loss Output: 21 dB

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-ADM-8095P Marki Microwave	Evaluation Board for ADM-8095PSM

Technical Inquiry Request for ADM-8095PSM Amplifier

Fields marked with * are required.

Product Specifications For ADM-8095PSM Amplifier

Part Number: ADM-8095PSM Manufacturer: Marki Microwave Product Description: Amplifier, HDR, Gain Block, 0.09 to 10 GHz, 18 dB, +21 dBm, SMT

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 9

$29.20

10 - 24

$26.86

Request a Pricing Quote for greater quantities
